A-509R
7 REC SELECTOR switch /indicator(For TAPE 1/CDR/MD terminals)
This switch is used to select the recording source component. The signal from the selected component is output at the TAPE1/ CD-R/MD jacks for recording. To select a recording source component, press the REC SELECTOR switch so that the indicator of the desired source component lights up. When this switch is set to [TUNER] or [CD], the signal from the selected component can be recorded regardless of the input selector switch and TAPE2 MONITOR button settings. CD : To record from the equipment connected to the CD terminals. TUNER : To record from the equipment connected to the TUNER terminals. SOURCE : To record from the equipment selected by the INPUT SELECTOR knob. OFF : In this position, nothing from the REC terminals of TAPE 1/CD-R/MD is output. Set to this position when not recording; the cassette deck will be disconnected, improving sound quality. NOTE: The function selected using the INPUT SELECTOR knob will be recorded irrespective of the position of the REC SELECTOR switch (TAPE 2 MONITOR terminals).
0 LOUDNESS button/indicator
Use when listening at low volume level. On : The indicator lights. Boosts low and high frequencies to give added punch to playback even at low volume level. Off : The indicator goes out. Should normally be left in this position. NOTE: This button does not operate at DIRECT ON mode.
- TREBLE tone control
Use to adjust the high-frequency tone. The center position is the flat (normal) position. When turned to the right, the high-frequency tone is emphasized; when turned to the left, the high-frequency tone is de-emphasized. NOTE: This control does not operate at DIRECT ON mode.
= BASS tone control
Use to adjust the low-frequency tone. The center position is the flat (normal) position. When turned to the right, the low-frequency tone is emphasized; when turned to the left, the low-frequency tone is de-emphasized. NOTE: This control does not operate at DIRECT ON mode.
~ PHONES jack
When using headphones, insert the plug into this jack.
8 BALANCE control
Should normally be left in the center position. Adjust the balance if the sound is louder from one of the speakers. If the right side is louder, turn toward the L (left) position and if the left side is louder, turn toward the R (right) position. NOTE: This control does not operate at DIRECT ON mode.
! SPEAKERS B (ON/OFF) button/indicator
Use this button to listen to the speaker system connected to the SPEAKERS B terminals. On : The indicator lights. Sound is heard from the speaker system. Off : The indicator goes out. No sound is heard from the speaker system. Set to this position when listening with headphones.
9 DIRECT/SB MODE button/indicator
Press and hold the button for more than 3 seconds to switch SB mode ON. (Volume indicator goes out) Press and hold the button for more than 3 seconds again to switch SB mode OFF. (Volume indicator lights) [DIRECT] Use this button when you do not wish to pass the output from input terminal equipment through the various frequency adjusting circuits (BASS, TREBLE, BALANCE, LOUDNESS). On : The indicator lights. The signals input through the input terminals are reproduced without passing through the various frequency adjusting circuits. This results in flat, pure sound which is a more faithful reproduction of the input source. Off : The indicator goes out. The signal passes through the various frequency adjusting circuits. [SB MODE] The SB mode is a special mode in which the amplifier does not accept remote control except power ON/OFF (But all of the facilities can be controled by manual as same as SB mode OFF.). Fix the VOLUME control near the center position.In this mode, the set can be used as a power amplifier which amplifies the LINE/SURROUND BACK input (the function name is LINE/SB) with a input sensitivity of 1V. For example, when the set is combined with one of Pioneer's Surround Back compatible receiver, the set can be used sa the Surround Back amplifier. (For details, please refer to the instruction manual of the receiver.)
@ SPEAKERS A (ON/OFF) button/indicator
Use this button to listen to the speaker system connected to the SPEAKERS A terminals. On : The indicator lights. Sound is heard from the speaker system. Off : The indicator goes out. No sound is heard from the speaker system. Set to this position when listening with headphones.
