CAUTION WHEN SERVICING
Precautions to be taken during servicing (1) Using extension jigs Connect between MAIN P.W.B. and CD mechanism with an extension jig during function check of CD mechanism.
Extension jig
1 13 26 14
MAIN P.W.B
BKC-JIG(1) BKC-JIG(2)
26 14 13 1
CD Mechanism
BOTTOM view
�
Check the PIN number of circuit board (BKC-JIG 1 / 2) before installing a jig circuit board. (See the photo) Parts name BKC-JIG Parts number SV-J00-106-010
�4�
|
|
|
> |
|
|
