PRACTICAL SERVICE FIGURE
<TUNER SECTION>
<FM SECTION> IHF Sensitivity : (THD 3%) Less than 19dB [at 88.0MHz] Less than 18dB [at 98.0/108.0MHz] Signal to noise ratio : More than 57dB [at 98.0MHz ] Distortion(Input 54dB) : Less than 1.5% [at 98.0MHz ] Distortion(Input 120dB) : Less than 5.0% [at 98.0MHz ] Stereo separation : More than 18dB [at 98.0MHz] Intermediate frequency : 10.7MHz ±0.1MHz <AM SECTION> Sensitivity : S/N (10dB) Signal to noise ratio :
<DECK SECTION>
Tape speed : Wow & flutter : Take-up torque : F.F & REW torque : Distortion : S/N ratio : Max Noise level : Min Noise level : Erasing ratio : Test tape : 3000Hz +90 / -60Hz Less than 0.4% (R.M.S) 30 ~ 60g-cm (FWD) 55 ~ 140g-cm Less than 3% (PB,DC) Less than 5% (REC/PB,DC) More than 35dB (PB, AC, DC) More than 25dB (REC/PB, AC, DC) Less than 45mV (PB, DC, AC) Less than 1mV (PB, DC) Less than 1.2mV (PB, AC) More than 45dB TTA�100 TTA�210 TTA�602
Less than 45dB [at 600/1000/1400kHz] More than 35dB [at 600/1000/1400kHz Distortion(Input 74dB) : Less than 1.5% [at 1000kHz] Distortion(Input 120dB) : Less than 3.0% [at 1000kHz] Intermediate frequency : 455kHz±3.5kHz
24
|
|
|
> |
|
