Section
Audio Adjustments
10
! The time alignment value calculated by auto TA and EQ may differ from the actual distance in the following circumstances. However, the distance has been calculated by computer to be the optimum delay to give accurate results for the circumstances, so please continue to use this value. When the reflected sound within a vehicle is strong and delays occur. When delays occur for low sounds due to the influence of the LPF on active subwoofers or external amps. ! Auto TA and EQ changes the audio settings as below: The fader/balance settings return to the center position. (Refer to page 45.) The graphic equalizer curve switches to FLAT. (Refer to page 51.) When a subwoofer is connected to this unit, it will be adjusted automatically to both subwoofer output and high pass filter setting for rear speaker. ! If you carry out auto TA and EQ when a previous setting of this already exists, the setting will be replaced.
3 Turn the ignition switch to ON or ACC. If the cars air conditioner or heater is turned on, turn it off. Noise from the fan in the air conditioner or heater may prevent correct auto TA and EQ.
# Press SOURCE to turn the source on if this unit is turned off.
4 Select the position for the seat on which the microphone is placed. Refer to Using the position selector on page 44.
# If no position is selected before you start auto TA and EQ, Front Left is selected automatically.
5 Press SOURCE and hold until the unit turns off. 6 Press and hold EQ to enter the auto TA and EQ measurement mode. The front panel opens automatically. 7 Plug the microphone into the microphone input jack on this unit.
Carrying out auto TA and EQ
1 Stop the car in a place that is as quiet as possible, close all doors, windows and the sun roof, and then turn the engine off. If the engine is left running, engine noise may prevent correct auto TA and EQ. 2 Fix the supplied microphone in the center of the headrest of the drivers seat, facing forward, using the belt (sold separately). The auto TA and EQ may differ depending on where you place the microphone. If desired, place the microphone on the front passenger seat to carry out auto TA and EQ.
English
55
8 Press MULTI-CONTROL to start the auto TA and EQ.
En
|
|
|
> |
|
