Setting the BP battery preset 1. Set The SYSTEM MENU (Refer to Section 2-25), and select the �BP battery preset mode� (Menu No. 513). (Fig. E�) 2. Press the RESET (MENU SET) button to blink the voltage on the display window (Fig. F�). 3. Press the SHIFT button while pressing the ADVANCE button. 4. Note down the voltage on the display window. 5. Change the value by pressing the ADVANCE button, and move to the next digit with the SHIFT button (Fig. G�). For your reference, the voltage increases by about 0.02 V when the right digit value is increased by one step. 6. Press the RESET (MENU SET) button. (The value set will be written in the EEPROM). �YES� will be displayed when the desired voltage is set (Fig. H�). �no� will be displayed when an error occurs while writing in the EEPROM and the value could not be set (Fig. I�). In this case, repeat steps 1 to 6. m . Set the voltage as 13.00 ± 0.01 V. . The voltage value shown on the display window is for reference. . If this menu is set by mistake, always press the MENU button to exit this menu. Never press the RESET (MENU SET) button. When pressing the RESET (MENU SET) button, the data being set will be written. . If the value at step 4 was not taken down, change the value using the values at shipment on the previous page as reference.
G� A/D conversion value blinking display H� Save OK I� Save NG Display window (LCD) E� Blinking menu No. (When changed) F� The voltage display blinking
2-40
DSR-1/1P/V1
|
|
|
> |
|
