SPECIFICATIONS
<FM tuner section> Tuning range Usable sensitivity (IHF) Antenna terminals <AM tuner section> Tuning range Usable sensitivity Antenna <Amplifier section> Power output Outputs 87.5 MHz to 108 MHz 13.2 dBf 75 ohms (unbalanced) AUDIO OUT (REC OUT) : 300 mV (1 kohm) VIDEO OUT (MONITOR) : 1 Vp-p (75 ohms) SUPER WOOFER : 1.5 V FRONT SPEAKERS IMP : 8 ohms : accepts speakers of 8 ohms or more SURROUND SPEAKERS IMP : 8 ohms : accepts speakers of 8 ohms or more CENTER SPEAKERS IMP : 8 ohms : accepts speakers of 8 ohms or more PHONES (stereo jack) : accepts headphones of 32 ohms or more -20 dB
531 kHz to 1602 kHz (9 kHz step) 530 kHz to 1710 kHz (10 kHz step) 350 µV/m Loop antenna
Front 100 W + 100 W (40 Hz - 20 kHz, T.H.D. less than 1 %, 8 ohms) 120 W + 120 W (1 kHz, T.H.D. less than 10 %, 8 ohms) Rear (Surround) 100 W + 100 W (40 Hz - 20 kHz, T.H.D. less than 1 %, 8 ohms) 120 W + 120 W (1 kHz, T.H.D. less than 10 %, 8 ohms) Center 100 W (40 Hz - 20 kHz, T.H.D. less than 1 %, 8 ohms) 120 W (1 kHz, T.H.D. less than 10 %, 8 ohms) 0.1 % (55 W, 1 kHz, 8 ohms, Front) AUDIO IN PHONO : 2.5 mV, adjustable (47 kohms) VIDEO 1/DVD/MD, VIDEO 2/ LD/TV, VIDEO 3, CD : 300 mV, adjustable (47 kohms) TAPE MONITOR : 350 mV, adjustable (47 kohms) AUX : 300 mV, adjustable (47 kohms) 5.1CH INPUT FRONT, CENTER, SURROUND SUB-WOOFER : 300 mV (47 kohms) DIGITAL IN COAXIAL (VIDEO 2) : OPTICAL (VIDEO 1) : OPTICAL (VIDEO 3) : accept linear PCM signals and bit stream of Dolby Digital and DTS Surround (32 kHz, 44.1 kHz, 48 kHz and 96 kHz) VIDEO IN : 1 Vp-p (75 ohms)
Muting <General> Power requirements Power consumption Power consumption in standby mode Dimensions of main unit (W x H x D) Weight of main unit
120 V AC, 60 Hz 170 W ECO OFF : 34 W ECO ON : 1.1 W 430 x 155 x 402 mm (17 x 61/8 x 157/8 in.) 9.8 kg (21 lb 10 oz.)
� Design and specifications are subject to change without notice. � Manufactured under license from Dolby Laboratories Licensing Corporation. �DOLBY�, the double-D symbol and "PRO LOGIC" are
Total harmonic distortion Inputs
trademarks of Dolby Laboratories Licensing Corporation. � Manufactured under license from Digital Theater System, Inc. US Pat. No. 5,451,942 and other worldwide patents issued and pending. "DTS" and "DTS Digital Surround" are trademarks of Digital Theater System Inc. C1996 Digital Theater system, Inc. All rights reserved.
ACCESSORIES / PACKAGE LIST
REF. NO. PART NO. 1 2 3 4 8B-AR2-903-010 87-006-226-010 87-043-115-010 8A-AR2-701-110
KANRI DESCRIPTION NO. IB,U(ESF)M ANT,LOOP AM ANT-FEEDER,FM RC UNIT,RC-AAR02 BLK
�2�
