SECTION 2 DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. HELICAL ANTENNA REMOVAL
Helical antenna
1
2-2. CABINET (REAR) ASSY REMOVAL
2 Screws
2 Screws
Claw Cabinet (Rear) assy
3
Battery case lid
1
3
3
Claws
4
Claws
