Installing the Antenna Units
Incar antennas have a lower reception sensitivity than antennas intended for outside mounting. The picture may not appear or may be disturbed if the signal in your area is weak.
� Attach the antenna to the inner glass surface of the rear window using double-sided tape. Carefully check the installation location as the tape can only be stuck on once. � If the surface temperature of the glass of the rear window is low, warm it by turning on the power of the rear defogger. A cold window glass surface will weaken the adhesive strength of the double-sided tape. Also, if installation inside the cabin is performed on a day with high humidity or when it is raining, the high humidity level will weaken the adhesive strength of the doublesided tape. � Do not install the antenna in a location where it may obstruct the field of view during driving, such as on the windshield.
1 Check the location where the antenna is to be
attached.Clean off any grease or dirt from the installation location using the supplied glass cleaner (Accessory B), clean the area with water and allow to dry.
Antenna parts
Antenna unit
Clean the glass thoroughly as failure to clean the glass can not only weaken the adhesive strength of the double-sided tape, but may also cause it to come loose.
2 Remove the protective strips from the antenna
parts and the back of the antenna unit.
3 Attach the double-sided tape of the antenna
parts and the antenna unit to the rear windshield glass. Attach the double-sided tape by firmly pressing down from the top. Secure cables using the supplied clampers.
Bundle cables with the clamper bar
Rear window
4 After attaching the antenna with the doublesided tape, allow it to sit undisturbed for 24 hours. Take care not to apply force to the antenna or allow it to get wet during this time.
(Accessory C)
5 Wire the antenna cable to TV tuner unit.
Rear seat
3
|
|
|
> |
|
