3.2 NETWORK ASSY (FRWN-187)
Network HPF (FRWN-187)
A 27 F/250 V 33 F/250 V White with Black Line
Red
0.22 mH
INPUT
2.2 mH 1.8 mH 3.9 F/250 V White
Mid
Black Red
White with Black Line B 4.7 /10 W 1.5 F/250 V 0.47 mH White
Tweeter Black
0.27 F/250 V
1 F/250 V White with Black Line White
0.017 mH
Super-Tweeter
C 2 Black Tapes start lead + S-TWEETER + -
INPUT
-
white tape
start lead
Start LEAD
D Start lead
Add glue around single wire
Start LEAD
E
Black Tape
White Tape
F + MEDIUM + TWEETER
8
1 2
S-81-K
3 4
|
