There are currently no product reviews.
 ;
This scanned manual is well done in that most all the pages except for one is straight and clear- the way I would do them. One page was upside down but that happens. For the money that is charged on this site you get a pretty good deal. Now with complex repairs, I still prefer to us paper manuals which I have to buy at stereomanuals but the one I got here was much less than the $45 he was charging but this is a larger than normal manual for three different units. I am a picky manual user because I have used original manuals from Sony and Teac.
;
Very useful service manual, was exactly what i needed.Good quality,reasonable price.Thank you.
;
Acurate informations inside the SM and I could repair my old Sansui SC-3330 without any problems. Thanks.
;
I used it to repair a NAD 7030, but unfortunately, the 7045 is different !
But documentation was useful.
;
Content A4 and A3 format pages. Exactly what I needed to restore my old receiver.
SPECIFICATIONS
Track system: Micro cassette, 2 tracks 1 channel, monaural Usable tapes: (Normal position type) Frequency response: 250 - 5,000 Hz (2.4 cm/sec) EIAJ Tape speed: 2.4 cm/sec or 1.2 cm/sec switchable Microphone: Electret condenser microphone (monaural) Maximum output: 110 mW (EIAJ/DC) Output jack: EARPHONE jack (monaural mini-jack) (1) Other jack: DC 3 V jack Speaker: Diameter 36 mm, 4 ohms Recording system: DC bias Erasing system: Magnet erasure Power sources: DC 3 V using two size AA (R6) batteries AC house current using an optional AC adaptor Aiwa AC-D302 Battery life Battery (EIAJ Recording) Battery life: Manganese (R6P) batteries Approx. 7 hrs Alkaline (LR6) batteries Approx. 24 hrs Dimensions: 63.8 (W) x 121(H) x 25.7 (D) mm (2 5/ x 4 7/ x 1 1/ in) Weight: Approx. 116 g (4.1 oz.) (excluding batteries)
8 6 16
� Design and specifications are subject to change without notice.
ACCESSORIES / PACKAGE LIST
REF. NO. PART NO. 1 KANRI DESCRIPTION NO. 8A-HX8-914-010 IB,YL(3L)C-M107
�2�
|
|
|
> |
|
