PREPARATIONS
Connection
Plug in the AC power cord to the AC power outlet after all other connections are made.
1 Connect the SUB WOOFER or SUPER WOOFER jack on the unit (stereo system, receiver, etc) side a to the INPUT (FROM SUPER WOOFER TERMINAL) jack on the powered subwoofer b with the supplied connecting cord.
Positioning
Because low-frequency sound reproduced by the powered subwoofer is mostly non-directional, the listener will be unable to localize the bass source. Accordingly, the powered subwoofer provides maximum flexibility in terms of positioning. For the most effective low-frequency sound, the powered subwoofer should be placed on the floor close to a wall or in a corner of the room.
En
(Position example)
2 Connect the AC power cord to an AC outlet.
4
