SPECIFICATIONS
Input terminal Input sensitivity/impedance Power output Frepuency response Speaker type Speaker unit Power requirement Power consumption Dimensions (w/h/d) Weight INPUT jack 250 mV/47 kilo ohms (at 60 Hz) 60 W (8 ohms, T.H.D. 1 %) 40 Hz � 200 Hz Dynamic bass system 16 cm (6.5 in.) AC 120 V, 60 Hz 50 W 235 x 265 x 405 mm (93/8 x 101/2 x 16 in.) 6.4 kg (14 lbs 2 oz.)
� Design and specifications are subject to change without notice.
ACCESSORIES / PACKAGE LIST
REF. NO. PART NO. 1 2 KANRI DESCRIPTION NO. 8B-YP5-903-010 IB,U(ESF)F 87-YP3-632-010 CORD ASSY,PIN P-C285V-30
�2�
 $4.99 TSWM5 AIWA
Owner's Manual Complete owner's manual in digital format. The manual will be available for download as PDF file aft…
|
