PIONEER VSX-AX5AI-G/DLXJ
Service Manual


Tweet about this product and get $1.00 of store credit for instant use!
  • Contains Circuit Diagrams
  • Download
  • PDF Format
  • Complete manual
  • Language: English
Price: $4.99

Description of PIONEER VSX-AX5AI-G/DLXJ Service Manual

Complete service manual in digital format (PDF File). Service manuals usually contains circuit diagrams, printed circuit boards, repair tips, wiring diagrams, block diagrams and parts list. Service Manual ( sometimes called Repair Manual ) is used mainly by technicians.

If You just want to know how to use Your tv, video, mp3 player etc. You should look for Owner's Manual. After placing order we'll send You download instructions on Your email address.

The manual is available in languages: English

Not yet ready
You must purchase it first

Customer Reviews
There are currently no product reviews.
Other Reviews
 15L30 SALORA Service Manual by Libor Sindelar;
It was helpful to get schematic with waveforms in important points and lot of service information. Manual is good quality, fast delivered. Of course it is hardcopy of paper one with all its disadvantages.
 HXA351W AKAI Service Manual by Thomas Marshall;
I want to give you a real heads-up for your desire to enable such people as I to acquire the information I need to maintain the older types of equipment such as this Akai HXA351W. You do a swell job with all the processes you have to perform so I can have a legible, thus usable document which does not send me crazy trying to figure out the blurry text of a bad copy. Very well done, Thomas.
 PCM-800 SONY Service Manual by Alexander French;
This manual is very well presented and after printing out looks about as close to an original as I think you can get. The quality is second to none. The content of the manual is comprehensive and I think it would be well suited to an audio repair professional which I'm not but I did find it very informative and helpful. The cost of the manual is more than covered by the money I'll save when I change the keep memory battery now I have the relavant info. Very pleased with my purchase and can recommend it wholeheartedly as I can other manuals I've downloaded from this site. Regards Limey Alex
 WM-R55 SONY Service Manual by Gaetano Amatucci;
Complete manual including mechanical part in good pdf quality. Shaded greys of the pcb due to pdf not perfect but usable.
 PMA830 DENON Service Manual by David Anderson;
Nice pdf file of the manual sent promptly. Thanks.

Text excerpt from page 131 (click to view)
5

6

7

8

4 Diagnostic mode
This mode is only for servicing and checking the circuit design, and not open to users. When the STEREO/DIRECT key and TONE + key are both held pressed for 2 seconds in Standby mode, the power is turned on, and the number of times of each defect or Speaker relay off by abnormality detection is sequentially displayed on the FL display. Displayed items: � DC detection � Overload detection � Fan detection � Temperature detection Hold the STEREO/DIRECT key and TONE + key pressed for 2 seconds in Standby mode.
B A

PROT CHK DCDET PROT CHK OVERLOAD PROT CHK FANSTOP PROT CHK TEMP

003 Display changes automatically every 3 seconds. 012

000

000

C

When the MULTI CH IN key and TONE � key are both held pressed for 2 seconds in standby mode, all clear the counter for detection.

Protection Process List
Item Purpose Detection Method Process Turns muting on and speaker relay off, then turns off the power after 3 seconds. Warning Indication Remarks To detect amplifier damage (defect status) A process to DC protect speakers detection (for protection of connected external devices) To detect overloading (abnormal status) With lowload driving or a short circuit of the speaker terminals (for protection of the amplifier) Flashing "AMP ERR" for Once detected and turned 3 seconds. the power off, input a key Flash the standby LED never again. after the power off.

Detects when the DC_DET port becomes "L".

D
Turns muting on and Detects when the AMP_OL port speaker relay off, and becomes "L" (checks by interrupt). immediately turns off the power. Detect temperature more than 100°C. Turns muting on and speaker relay off. Rotate the fan None

AMP overload

Continue flasing with "OVERHEAT" Mute, relay and warning indications is leading hold.

Fan control

Protection function against a temperature rise at the heat sink

Detect temperature of 90 to 100°C. Rotate the fan Detect temperature of 74 to 90°C. Detect temperature of 69 to 74°C. A condition except the above. Rotate the fan Fan is leading hold Stop the fan Turns muting on and speaker relay off, then Flashing "FAN STOP" turns off the power after 3 for 3 seconds seconds. Turns 12V_TRG port to "L", then turns off the 12V output.

Mute off & relay on (normal mode)

E

Fan stop

To know that the rotating fan is forcibly stopped

Detects when the FAN_DET port becomes "L".

If the FAN_DET port becomes "H" within 3 seconds, the unit resets automatically. After the power off, the key input is possible once again. Only a fan that is assigned 12V TRIG is valid.Release the FL indication with the power on/off.

Detects when the 12V_DET port 12V trigger To detect the shortcircuit of 12V trigger circuit becomes "H".

Flashing "12V TRI ERR"

F

VSX-AX5Ai-S
5 6 7 8

131
