MECHANICAL PARTS LIST 1/1
REF. NO 1 1 2 3 3 4 5 6 6 7 8 9 A B
KANRI DESCRIPTION NO. 88-XX2-010-010 PANEL,FR 5 BLK<YUB> 88-XX2-001-010 PANEL,FR 5'<YUW> 88-ZL1-360-010 SPR-T,LID 88-XX2-002-010 LID,INT 5<YUW> 88-XX2-011-010 LID,INT 5 BLK<YUB> 88-XX2-004-010 88-XX2-005-010 88-XX2-003-010 88-XX2-012-010 88-XX2-202-010 87-A61-295-010 88-XX2-201-010 88-ZL1-319-010 87-261-032-410 REFLECTOR,LED REFLECTOR,LED EJ BTN,EJECT<YUW> BTN,EJECT BLK<YUB> HLDR,BOT SOCKET,2P A3-SP(B) HLDR,TOP S-SCREW,PWB-MAIN V+2-3 GLD
PART NO.
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color B Black C Cream D Orange G Green H Gray L Blue LT Transparent Blue N Gold P Pink R Red S Silver ST Titan Silver T Brown V Violet W White WT Transparent White Y Yellow YT Transparent Yellow LM Metallic Blue LL Light Blue GT Transparent Green LD Dark Blue DT Transparent Orange
25
|
|
|
> |
|
