SPECIFICATIONS
3-beam laser Semiconductor laser 4-times oversampling digital filter + 1-bit DAC 20 - 20,000 Hz PHONES / LINE OUT jack (stereo mini-jack) 524AHR: DIGITAL OUT jack (optical) Maximum output: 523AHR,524AHR: 12 mW +12 mW (16 ohms at 1 kHz) 522AEZ: 10 mW +10 mW (16 ohms at 1 kHz) 500 mV (47 k ohms at 1 kHz) Power supply: DC 3 V using two LR6 (size AA) alkaline batteries 522AEZ,524AHR: DC 2.4 V using supplied rechargeable batteries 523AHR: DC 2.4 V using commercially available (Ni-Cd 1.2 V 700 mAh) rechargeable batteries AC house current using the supplied AC adaptor Maximum outside: 128 (W) x 25.8 (H) x 129.5 (D) mm dimensions (excluding projecting parts and controls) Weight: Approx. 206 g excluding batteries AC adaptor AC-D603: Rated voltage: 522AEZ: AC 230 V, 50 Hz 523AHR,524AHR: AC 115/230 V switchable, 50/60 Hz Tracking system: Laser pickup: D/A conversion: Frequency response: Output: Supplied headphones HP-M062 <522AEZ> Type: In-ear type Impedance: 16 ohms Sensitivity: 103 dB/mW Recommended commercially available headphones <522AEZ> Type: In-ear type / Vertical type / Headband type Impedance: 16 - 32 ohms Sensitivity: 96-105 dB/mW
� Design and specifications are subject to change without notice.
�2�
|
|
|
> |
|
