6.1.5 MECHANISM ADJUSTMENT
A
1 Tangential and Radial Height Coarse Adjustment START
� Remove the servo mechanism. � Remove a Spacer for height adjustment attached to the back side (shaded area) of the Servo Mechanism (Float Base) with nippers. Cautions: Because there is not a Spacer for height adjustment in adjustment after the second time, will keep it at need. (This parts is Traverse mechanism exclusive use of a model for 2003 years) 7.3mm
B
Servo Mechanism
Float Base
Put a spacer between a Tangential (or Radial) adjustment screw and Mechanism Base and turn each screw to adjust the height. (Refer to "6.1.1 ADJUSTMENT ITEMS AND LOCATION".)
Spacer for Height adjustment
C
Note: Before removing the flexible cable for the pickup, soldering of the pickup circuit is necessary. For details, see "7.1.9 DISASSEMBLY".
Turn a flat side into bottom
D
E
F
82
1 2
XV-PR7DV
3 4
|
|
|
> |
|
