EQ DISPLAY
MODE 0-9, +10
SOUND ADJUSTMENT
Volume or tone adjustment does not affect recording.
VOLUME (VOL) BAND r, t c PLAY VOL s STOP
Press VOLUME N or M. The volume level is displayed as a number from 0 to MAX (25). � The volume level is automatically set to 14 if the power is turned off when the volume level is set to 15 or more. (except when turning the power back on within 4 seconds) � Pressing DISPLAY on the remote control displays the adjusted volume level.
3-mode equalizer
PRESETTING STATIONS
You can preset up to 15 stations in each band.
1 2
Select a station. Press s STOP/MEMORY * once so that �M� is displayed to store the station.
A station is assigned a preset number, beginning from 1 in consecutive order for each band. Preset number
Press one of the 3-mode equalizer buttons (ROCK, POP, JAZZ). The selected mode R (Rock), P (Pop) or J (Jazz) appears in the display for 4 seconds. To cancel, press the selected mode button. ROCK - Emphasizes the high and low range of music. POP - Emphasizes voice and midrange of music. JAZZ - Emphasizes the low range of music. When using the remote control, press EQ repeatedly until the desired mode is selected. The equalizer mode changes to ROCK, POP, JAZZ or no equalization, cyclically.
T-BASS system
The T-BASS system enhances the realism of lowfrequency sound. Press T-BASS to turn it on or off. Frequency * or s STOP on the remote control
En
3
Repeat steps 1 and 2.
The next station will not be stored if a total of 15 preset stations have already been stored for a band.
To listen to preset stations
Select a band then press A PLAY/PAUSE repeatedly. c PLAY on the remote control is also available.
To select a preset number directly with the remote control
Press the numbered buttons 0-9 and +10. Example: To select number 15, press +10 and 5. To select number 10, press +10 and 0.
To clear a preset station
Select the preset number first. Within 4 seconds, keep s pressed until �M� and the preset number disappear in the display. The higher numbers in the band are decreased by one.
ENGLISH
7
